| Cable mm2 | Dimensions | Product Code | ||||||
| A | C | D | G | H | B | J | ||
| 6 | 3 | 4.6 | 2 | 20 | 0.8 | 3 | - | HWB6 |
| 10 | 4.4 | 6 | 2 | 25 | 0.8 | 4 | - | HWB 10 |
| 16 | 5.5 | 7.5 | 2 | 25 | 1 | 5 | 1.5 | HWB 16 |
| 25 | 7 | 9 | 2 | 30 | 1 | 7 | 1.5 | HWB 25 |
| 35 | 8 | 10.4 | 2 | 35 | 1.2 | 8 | 1.5 | HWB 35 |
| 50 | 9.5 | 11.9 | 2 | 40 | 1.2 | 9 | 0.5 | HWB 50 |
| 70 | 12 | 14.8 | 3 | 45 | 1.4 | 12 | 3 | HWB 70 |
| 95 | 13.5 | 16.3 | 3 | 50 | 1.4 | 13 | 3 | HWB 95 |
| 120 | 15.5 | 18.7 | 4 | 55 | 1.6 | 15 | 3 | HWB 120 |
| 150 | 17 | 20.6 | 4 | 60 | 1.8 | 16 | 3 | HWB 150 |
| 185 | 18.5 | 22.9 | 4 | 65 | 2.2 | 18 | 5 | HWB 185 |
| 225 | 20.5 | 24.9 | 5 | 75 | 2.2 | 20 | 5 | HWB 225 |
| 240 | 22 | 26.4 | 5 | 80 | 2.2 | 21 | 5 | HWB 240 |
| 300 | 24 | 29.6 | 5 | 85 | 2.8 | 23 | 5 | HWB 300 |
| 400 | 28.5 | 34.7 | 7 | 95 | 3.1 | 27 | 5 | HWB 400 |
| 500 | 30.5 | 37.5 | 7 | 105 | 3.5 | 30 | 5 | HWB 500 |
| 630 | 34.5 | 42.5 | 8 | 115 | 4 | 33 | 5 | HWB 625 |
